WM8198SCDS

analogue front end/digitiser IC, SSOP-28, GND - 0.3V to GND + 7V

Rated 5 Rating 5 | reviews | Write a review

Price:: US $0.88~1.29 / piece [Get Latest Price]

Reference price:

Qty (lots)	Price/lot
	US $0.88~1.29

PartNumber:: WM8198SCDS

Brand:: Wolfson Microelectronics plc - Wolfson | Pack: SSOP | D/C: 09+

Availability:: Supply Ability: 10000/Week Can Ship Immediately
Delivery: 10-15 Business Days (ships out within 3 Business days)

Quantity:: piece

Total Price:: US $0

Place Order via Escrow Service

Sold By

Ms. Tiffany's store

(China (Mainland))

add to my favourite

100% Positive feedback

Detailed seller ratings

Visit Store

Contact Now

Esrcow Service

Place orders confidently and securely via it

Safe payments
Quick and easy transactions
Free service charges

Learn More >>

Previous Next

Products Upload time: 2011-10-19

From Other Seller

Part Number:WM8198SCDS
US $0.88 - 1.29
EKXG401ELL6R8MJ16S

US $5.00 - 5.00 / Piece
(0) Remove
TMS320C6414TBGLZA7

US $58.00 - 65.00 / Piece
(0) Remove
Quantity:

piece

Product Summary

The WM8198SCDS is a 16-bit analogue front end/digitiser IC which processes and digitises the analogue output signals from CCD sensors or Contact Image Sensors (CIS) at pixel sample rates of up to 6MSPS. The applications of the WM8198SCDS include Flatbed and sheetfeed scanners, USB compatible scanners, Multi-function peripherals, High-performance CCD sensor interface.

Parametrics

WM8198SCDS absolute maximum ratings: (1)Analogue supply voltage: GND - 0.3V to GND + 7V; (2)Digital supply voltages: GND - 0.3V to GND + 7V; (3)Digital ground: GND - 0.3V to GND + 0.3V; (4)Analogue grounds: GND - 0.3V to GND + 0.3V; (5)Digital inputs, digital outputs and digital I/O pins: GND - 0.3V to DVDD2 + 0.3V; (6)Analogue inputs (RINP, GINP, BINP) GND: - 0.3V to AVDD + 0.3V; (7)Other pins: GND - 0.3V to AVDD + 0.3V; (8)Operating temperature range: 0℃ +70℃; (9)Storage prior to soldering: 30℃ max / 85% RH max; (10)Storage temperature after soldering: -65℃ to +150℃; (11)Package body temperature (soldering, 10 seconds): +260℃; (12)Package body temperature (soldering, 2 minutes): +183℃.

Features

WM8198SCDS features: (1)16-bit ADC; (2)6MSPS conversion rate; (3)Low power ?212mW typical; (4)5V single supply or 5V/3.3V dual supply operation; (5)Single or 3 channel operation; (6)Correlated double sampling; (7)Dual Range Programmable Gain Amplifier (9-bit resolution); (8)Programmable offset adjust (8-bit resolution); (9)Programmable clamp voltage; (10)8 or 4-bit wide multiplexed data output formats; (11)Internally generated voltage references; (12)28-pin SSOP package; (13)Serial control interface.
