SN74ALVC164245DGGR

16-BIT, 3.3-V TO 5-V LEVEL, SHIFTING TRANSCEIVER, WITH 3-STATE OUTPUTS, TSSOP, 5.8 ns at 3.3 V, -0.5 to 4.6 Supply voltage

Rated 5 Rating 5 | reviews | Write a review

Price:: US $0.50~0.90 / piece [Get Latest Price]

Reference price:

Qty (lots)	Price/lot
	US $0.50~0.90

PartNumber:: SN74ALVC164245DGGR

Brand:: Texas Instruments - TI | Pack: TSSOP | D/C: 09+

Availability:: Supply Ability: 10000/Week Can Ship Immediately
Delivery: 10-15 Business Days (ships out within 3 Business days)

Quantity:: piece

Total Price:: US $0

Place Order via Escrow Service

Sold By

Ms. Tiffany's store

(China (Mainland))

add to my favourite

100% Positive feedback

Detailed seller ratings

Visit Store

Contact Now

Esrcow Service

Place orders confidently and securely via it

Safe payments
Quick and easy transactions
Free service charges

Learn More >>

Previous Next

Products Upload time: 2011-10-19

From Other Seller

Part Number:SN74ALVC164245DGGR
US $0.50 - 0.90
EKY-160ELL121MF11D

US $0.10 - 1.00 / Piece
(0) Remove
74AHC2G08VS SOP-8

US $2.00 - 2.00 / Piece
(0) Remove
Quantity:

piece

Product Summary

This 16-bit (dual-octal) noninverting bus transceiver SN74ALVC164245DGGR contains two separate supply rails. B port has VCCB, which is set to operate at 3.3 V and 5 V. A port has VCCA, which is set to operate at 2.5 V and 3.3 V. This allows for translation from a 2.5-V to a 3.3-V environment, and vice versa, or from a 3.3-V to a 5-V environment, and vice versa. The SN74ALVC164245DGGR is designed for asynchronous communication between data buses. The control circuitry (1DIR, 2DIR, 1OE, and 2OE) is powered by VCCA. To ensure the high-impedance state during power up or power down, the output-enable (OE) input should be tied to VCC through a pullup resistor; the minimum value of the resistor is determined by the current-sinking capability of the driver.

Parametrics

SN74ALVC164245DGGR absolute maximum ratings: (1)VCC Supply voltage range: VCCA -0.5 to 4.6 V; VCCB -0.5 6; (2)VI Input voltage range: Except I/O ports(2) -0.5 6; I/O port A(3) -0.5 to VCCA + 0.5 V; I/O port B(2) -0.5 V to CCB + 0.5; (3)IIK Input clamp current VI < 0 -50 mA; (4)IOK Output clamp current VO < 0 -50 mA; (5)IO Continuous output current ±50 mA; (6)Continuous current through each VCC or GND ±100 mA; (7)θJA Package thermal impedance(4): DGG package 70℃/W; DL package 63; GQL/ZQL package 42; GRD/ZRD package 36; (8)Tstg Storage temperature range: -65 to 150 ℃.

Features

SN74ALVC164245DGGR features: (1)Member of the Texas Instruments Widebus. Family; (2)Max tpd of 5.8 ns at 3.3 V; (3)±24-mA Output Drive at 3.3 V; (4)Control Inputs VIH/VIL Levels Are Referenced to VCCA Voltage; (5)Latch-Up Performance Exceeds 250 mA Per JESD 17.
