SN65HVD233DRG4

3.3-V CAN transceiver, SOP-8, -0.3 V to 7 V, High-Input Impedance

Rated 5 Rating 5 | reviews | Write a review

Price:: US $0.45~0.80 / piece [Get Latest Price]

Reference price:

Qty (lots)	Price/lot
	US $0.45~0.80

PartNumber:: SN65HVD233DRG4

Brand:: Texas Instruments - TI | Pack: SOP | D/C: 09+

Availability:: Supply Ability: 10000/Week Can Ship Immediately
Delivery: 10-15 Business Days (ships out within 3 Business days)

Quantity:: piece

Total Price:: US $0

Place Order via Escrow Service

Sold By

Ms. Tiffany's store

(China (Mainland))

add to my favourite

100% Positive feedback

Detailed seller ratings

Visit Store

Contact Now

Esrcow Service

Place orders confidently and securely via it

Safe payments
Quick and easy transactions
Free service charges

Learn More >>

Previous Next

Products Upload time: 2011-10-18

From Other Seller

Part Number:SN65HVD233DRG4
US $0.45 - 0.80
EKXG401ELL6R8MJ16S

US $5.00 - 5.00 / Piece
(0) Remove
IRF3205

US $0.80 - 2.50 / Piece
(0) Remove
Quantity:

piece

Product Summary

The SN65HVD233DRG4 is a 3.3-V CAN transceiver, which is used in applications employing the controller area network (CAN) serial communication physical layer in accordance with the ISO 11898 standard. It provides transmit and receive capability between the differential CAN bus and a CAN controller, with signaling rates up to 1 Mbps. The applications of the SN65HVD233DRG4 include SAE J1939 Standard Data Bus Interface, NMEA 2000 Standard Data Bus Interface, ISO 11783 Standard Data Bus Interface.

Parametrics

SN65HVD233DRG4 absolute maximum ratings: (1)Supply voltage range, VCC: -0.3 V to 7 V; (2)Voltage range at any bus terminal (CANH or CANL): -36 V to 36 V; (3)Voltage input range, transient pulse, CANH and CANL, through 100 Ω: -100 V to 100 V; (4)Input voltage range, VI (D, R, RS, EN, LBK, AB): -0.5 V to 7 V; (5)Receiver output current, IO: -10 mA to 10 mA; (6)Electrostatic discharge Human Body Model CANH, CANL and GND: 16 kV; (7)Operating junction temperature, TJ: 150℃.

Features

SN65HVD233DRG4 features: (1)Bus-Pin Fault Protection Exceeds ±36 V; (2)Bus-Pin ESD Protection Exceeds 16-kV HBM; (3)GIFT/ICT Compliant (SN65HVD234); (4)Compatible With ISO 11898; (5)Signaling Rates up to 1 Mbps; (6)Extended –7-V to 12-V Common-Mode Range; (7)High-Input Impedance Allows for 120 Nodes; (8)LVTTL I/Os Are 5-V Tolerant; (9)Adjustable Driver Transition Times for Improved Signal Quality.
