Product Summary

The MC68340PV16E is a high-performance 32-bit integrated processor with direct memory access (DMA), combining an enhanced M68000-compatible processor, 32-bit DMA, and other peripheral subsystems on a single integrated circuit. The MC68340PV16E CPU32 delivers 32-bit CISC processor performance from a lower cost 16-bit memory system. The combination of peripherals offered in the MC68340PV16E can be found in a diverse range of microprocessor-based systems, including embedded control and general computing. Systems requiring very high-speed block transfers of data can especially benefit from the MC68340PV16E’s DMA.

Features

MC68340PV16E features: (1)High Functional Integration on a Single Piece of Silicon; (2)CPU32-C68020-Derived 32-Bit Central Processor Unit: Upward Object-Code Compatible with MC68000 and MC68010, Additional 32-Bit MC68020 Instructions and Addressing Modes, Unique Embedded Control Instructions, Fast Two-Clock Register Instructions?0,045 Dhrystones/Second; (3)Two-Channel Low-Latency DMA Controller for High-Speed Memory Transfers: Single- or Dual-Address Transfers, 32-Bit Addresses and Counters, 8-, 16-, and 32-Bit Data Transfers, 50 Mbyte/Sec Sustained Transfers (12.5 Mbyte/Sec Memory-to-Memory).

Diagrams

MC68340PV16E block diagram

Image Part No Mfg Description Data Sheet Download Pricing
(USD)		 Quantity
MC68340PV16E
MC68340PV16E

IC MPU W/DMA 16MHZ 144-LQFP
Data Sheet
Negotiable
