Product Summary
The LM4040CIM3X-3.0 is a Precision Micropower Shunt Voltage Reference. Ideal for space critical applications, the device is available in the sub-miniature SC70 and SOT-23 surface-mount package. The LM4040CIM3X-3.0’s advanced design eliminates the need for an external stabilizing capacitor while ensuring stability with any capacitive load, thus making it easy to use. The applications of the LM4040CIM3X-3.0 are Portable, Battery-Powered Equipment, Data Acquisition Systems, Instrumentation, Process Control, Energy Management, Product Testing, Automotive, Precision Audio Components.
Parametrics
LM4040CIM3X-3.0 absolute maximum ratings: (1)Reverse Current:20 mA; (2)Forward Current:10 mA; (3)Power Dissipation (TA = 25℃):306 mW; (4)Storage Temperature:-65℃ to +150℃; (5)Soldering (10 seconds):+260℃; (6)ESD Susceptibility: Human Body Model:2 kV, Machine Model:200V.
Features
LM4040CIM3X-3.0 features: (1)Small packages: SOT-23, TO-92 and SC70; (2)No output capacitor required; (3)Tolerates capacitive loads; (4)Fixed reverse breakdown voltages of 2.048V, 2.500V,3.000V, 4.096V, 5.000V, 8.192V, and 10.000V.
Diagrams
| Image | Part No | Mfg | Description |  |
Pricing (USD) |
Quantity | ||||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 |
 LM4040CIM3X-3.0 |
National Semiconductor (TI) |
Voltage & Current References |
Data Sheet |
|
|
||||||||||||
|
LM4040CIM3X-3.0/NOPB |
National Semiconductor (TI) |
Voltage & Current References |
Data Sheet |
|
|
||||||||||||
